塑料洛氏硬度计
当前位置:首页 > 产品展示
塑料洛氏硬度计



XHR-150型塑料洛氏硬度计是一种专门测试非金属塑料、硬橡胶、合成树脂、摩擦材料及较软金属的硬度计。测试对象特殊,操作简便。试验力的施加、保荷和卸荷自动完成,消除人为操作误差。
适用范围
硬塑料、硬橡胶,铝、锡、铜、软钢、合成树脂及磨擦材料等。
XHR-150 Plastics Rockwell Hardness Tester adopts motorized testing method. Its testing force can be loaded, kept and unloaded automatically. Avoid man-made error and easy to use. It is therefore, welcomed by many users.
Usage Range:
Hard plastics, hard rubbers, aluminum, tin, copper, soft steel, synthetic resins, fricative materials, etc.
技术数据(Technical Specifications)



塑料洛氏标尺
( Plastics Rockwell Scales)
HRE, HRL, HRC, HRM, HRR

初试验力(Initial Testing Force)
10Kg (98.07N)
试验力(All Testing Force)
60Kg (588N), 100Kg (980N), 150Kg (1471N)
硬度读取
(Indication of Hardness Value)
表盘式(Dial )
保菏时间(Duration Time)
2 ~ 60S
试件最大高度
Max. Height of Specimen
170mm
仪器尺寸(Overall Dimension)
520X240X700MM  (长X宽X高, LXWXH)
仪器重量(Net Weight)
80 Kg
电源( Power Supply)
AC220V+5%, 50~60 Hz
执行标准 (Carried Standard)
GB7407 国家标准、JJG884检定规程
GB/7407 Chinese Standard and JJG884 Inspection Rule
标准配件、附件
(Standard Accessories)
直径3.175、6.35、12.7mm球压头,大平试台、中平试台、V型试台、硬度块(4),电源线
Diameter 3.175, 6.35, 12.7mm Ball Indenter, Large Testing Table , Medium Testing Table and V-shaped Testing Table, 4 pcs Hardness Blocks , Power Cable
